Product Description :

The BT-201 is a feature-rich Bluetooth audio module based on the CSR BC03MM7 chip. It is engineered to deliver a reliable and user-friendly wireless audio experience. The module supports key profiles like A2DP for high-quality stereo music streaming and AVRCP for convenient track and volume control from your Bluetooth device.

This module functions as a slave receiver, making it perfect for upgrading existing audio equipment with Bluetooth functionality. It outputs a decoded analog stereo signal via its left and right audio channels, ready to be amplified. With additional features like onboard microphone input for hands-free calling (HFP/HSP), integrated EEPROM for configuration storage, and a low power consumption design, the BT-201 is a comprehensive audio solution for DIY projects and commercial products alike.

Key Features :

• High-Quality Audio Streaming: Supports A2DP profile for stereo audio reception.

• Integrated Audio Decoding: Built-in DAC for SBC audio decoding.

• Hands-Free Calling: Supports HFP/HSP profiles with microphone input for headset functionality.

• Convenient Playback Control: AVRCP support allows for play, pause, next, and previous commands from the connected device.

• Multiple Input Options: Features both Bluetooth audio input and an auxiliary (AUX) line input.

• Easy Configuration: Uses a standard UART interface with AT commands for setup and control.

• Compact and Integrated: Comes with a built-in PCB antenna for a compact and robust design.

• Low Power Operation: Efficient power consumption suitable for portable audio applications.

Applications :

The BT-201 module is ideal for integrating wireless audio into various applications, including:

• Bluetooth Car Kits and Automotive Audio Systems

• Portable Bluetooth Speakers and Boomboxes

• Home Stereo and Hi-Fi System Upgrades

• Wireless Headphones and Headsets

• Intercoms and Hands-Free Communication Systems

• DIY Audio Projects and Prototypes

Technical Specifications :
