ASUS ROG Prime 650W Bronze Power Supply — ATX12V, 80 PLUS Bronze, Dual Ball Bearing Fan
The ASUS Prime 650W Bronze PSU is built for durability, efficiency, and reliable performance in everyday PCs and gaming builds. Featuring 80 PLUS Bronze certification, dual ball bearing fans, and premium low-ESR capacitors, this power supply delivers stable power while maintaining excellent lifespan and easy installation with flexible etched cables.
-
Key Features
-
650W Bronze Efficiency – 80 PLUS Bronze certified for reliable and efficient power delivery using premium low-ESR electrolytic capacitors.
-
Dual Ball Bearing Fans – Last up to twice as long as standard sleeve-bearing fans, ensuring durable cooling performance.
-
Flexible Etched Cables – Designed for easy bending and cleaner installations in tight spaces.
-
Comprehensive Protection – Equipped with OPP, OVP, UVP, SCP, OCP, and OTP safety features for stable, long-term operation.
-
Wide AC Input Range – Supports 100–240 Vac for worldwide compatibility.
-
Essential Connectivity – Includes 24-pin motherboard, CPU, PCI-E, SATA, and peripheral connectors for versatile system support.
Technical Specifications :
Category Details Model PRIME-650B-BLACK Form Factor Intel ATX12V PFC Type Active PFC Dimensions 150 × 150 × 86 mm Efficiency Certification 80 PLUS Bronze MTBF > 120,000 hours @ 25 °C Protection Features OPP / OVP / UVP / SCP / OCP / OTP Environmental Certification RoHS AC Input Range 100–240 Vac DC Output Voltage +3.3V / +5V / +12V / -12V / +5Vsb Maximum Load 20A / 20A / 54A / 0.3A / 2.5A Combined Load 110W / 110W / 648W / 3.6W / 12.5W Total Power Output 650W Cable Connectors - MB 24/20-pin ×1 - CPU 4+4-pin ×1 - PCI-E 8-pin ×2 - SATA ×5 - Peripheral ×3 Package Contents Power Cord ×1, CPU Cable (800 mm) ×1, PCI-E 1-to-2 Cable (600 mm) ×1, SATA 1-to-2 Cable (400+120 mm) ×1, SATA 1-to-3 Cable (400+120+120 mm) ×1, Peripheral 1-to-3 Cable ×1, User Manual ×1 Weight 2.2 kg (Single PSU) / 3.067 kg (With Packing) 0dB Technology Not Supported
-
