ROG Thor III 1600W Titanium Power Supply — ATX 3.1, GaN MOSFETs, GPU-First Voltage Regulation
Key Features
-
1600W Titanium Efficiency – 80 PLUS & Cybenetics Titanium certification with low-ESR capacitors for top-tier power efficiency.
-
GaN MOSFET Technology – Up to 30% more efficient than standard MOSFETs, with cooler and cleaner internal layouts.
-
GPU-First Voltage Regulation – Patented intelligent regulators improve voltage stability by up to 45%, ensuring smoother performance for demanding GPUs.
-
Magnetic OLED Power Display – Real-time power consumption monitoring; detachable and positionable on either side to fit any build orientation.
-
ROG Heatsink & Aluminum Chassis – Superior heat dissipation and dual ball-bearing fans that last twice as long as standard oil-sealed designs.
-
ATX 3.1 Compatible – Ensures enhanced voltage and current regulation to support the latest CPUs and GPUs.
-
Fully Modular Premium Cables – Embossed, soft-touch modular cables for easy management and a clean, professional build look.
-
Turbo Mode & 0dB Technology – Optimized fan curve with quiet operation at low loads, and a turbo switch for extra performance headroom.
Technical Specifications :
Category Details Model ROG Thor III 1600W Titanium Form Factor Intel ATX12V PFC Active PFC ATX Standard ATX 3.1 Efficiency Certification 80 PLUS Titanium / Cybenetics Titanium Power Output 1600W (115V–240V) / 1300W (100V–115V) Dimensions 200 × 150 × 86 mm MTBF > 120,000 hours @ 25 °C Protections OPP / OVP / SCP / OCP / OTP / UVP Environmental Certification RoHS Input Voltage (AC) 100–240 Vac Thermal Design ROG cooling solutions, ROG heatsink, aluminum chassis Output Voltage (DC) +3.3V / +5V / +12V / -12V / +5Vsb Max Load 30A / 25A / 133.3A / 0.3A / 3A Comprehensive Load 125W / 125W / 1600W / 3.6W / 15W Ports - Motherboard 24/20-pin ×1 - CPU 4+4-pin ×2 - PCI-E 6+2-pin ×4 - PCI-E 16-pin ×2 - SATA ×10 - Peripheral ×9 Package Contents Power Cable ×1, MB Power Cable (610 mm) ×1, CPU Cable (1000 mm) ×2, PCI-E Gen 5.1 16-pin Cable (750 mm) ×2, PCI-E 1-to-1 Cable (750 mm) ×4, SATA 1-to-4 Cable ×1, SATA 1-to-3 Cable ×2, Peripheral 1-to-3 Cable ×3, ARGB Cable (800 mm) ×1, ROG Sticker ×1, ROG Cable Ties ×6, Cable Ties ×12, Chassis Screws Pack ×1, User Manual ×1 Weight 2.80 kg (single PSU) AURA SYNC ARGB Compatible Cybenetics Noise Level TBD 0dB Technology Supported — Fan stops below certain load threshold 0dB Fan Button ON: Fan runs only under load / OFF: Fan runs continuously
-
